ST101 30W-240W New Led Street Lamp factory price china supplier best sell

Model No.	Power	LWH(mm)	IP Level	Protection Level
GLD-ST101S	50W-100W	618x230x116	IP66	IK09
GLD-ST101M	100W-150W	689x270x119	IP66	IK09
GLD-ST101L	180W-240W	826x325x120	IP66	IK09

[email protected]

Product Details

Model	GLD-ST101
Light Source	Integral LED Module
Power	50W/80W/100W/150W/180W/200W/240W
Led Chips	SMD3030 72pcs/96pcs/108pcs/144pcs/192pcs/240pcs/288pcs
Install tube Dia	D50/D60MM
Luminaire Efficacy	130-170lm/W
CCT	4000K (3000K/5000K/5700K upon request)
CRI	> 70/ > 80 (upon request)
Voltage	AC100-240V
Lifetime	100,000 hours at 25℃ ambient temperature
Beam angle	TYPE Ⅱ、Ⅲ
Driver	Philips、SOSEN、INVENTRONICS、Geolide
Options	Photocell Surge protection device (up to 20KV) 0.5m External cable(Other length upon request) Smart control device Motion detection
Materials	Housing: ADC12 die-cast aluminum Cover: Toughened Glass Screws: 304 stainless screws
Spray	Finished with high-end outdoor epoxy power, resistant corrosion
Color	Grey/Black/White
Tightness Level	IP66
Impact Resistance	IK09
Standards & Certifications	CE/ENEC/CB/GS/IEC/ROHS/LM80/TM21

Patented product, SKD parts supply is optional

Ningbo Geolide Illuminate Co., Limited is a professional China Die Casting Led Street Lights Housing Manufacturers and Street lamps factory&supplier, which is found in 2010 as a stock company focus on development, production, marketing of die casting High Power 30W/50W/100W/150W/180W/300W LED street light housing, Led light housing, Led Street Light, Led Garden Light, Led Flood Light, Led High Bay Light ETC. Our company mainly manufactures middle and high-end products.

Application
This heavy-duty, modern design and cost-effective LED street light housing fixture is typically used as a 30W-300W LED street lighting fixture. LED street lighting is used extensively in urban settings, along small town downtown main streets, in residential neighborhoods, in commercial districts, public squares, in industrial parks, at interstate highway interchanges, bridges, and rural intersections.
