Model No. |
Power |
L*W*H(mm) |
IP |
Work Voltage |
|
GLD-FL103 |
70W/100W |
353x221x56 |
IP65 |
AC220-240V |
|
GLD-FL103 |
200W/300W |
419x281x66 |
IP65 |
AC220-240V |
|
GLD-FL103 |
400W/500W |
586x440x89 |
IP65 |
AC100-240V |
|
GLD-FL103 |
600W/800W/1000W |
714x533x98 |
IP65 |
AC100-240V |
|
Model |
GLD-FL103 |
|
Light Source |
Integral LED Module |
|
Power |
70W/100W/200W/300W/400W/600W/800W/1000W |
|
Led Chips |
Lumileds, Cree |
|
Luminaire Efficacy |
100-120lm/W |
|
CCT |
4000K (3000K/5000K/5700K upon request) |
|
CRI |
> 70/ > 80 (upon request) |
|
Voltage |
AC180-240V |
|
Lifetime |
100,000 hours at 25℃ ambient temperature |
|
Driver |
Meanwell, Sosen, Done.Lufud |
|
Materials |
Housing: ADC12 die-cast aluminum |
|
Spray |
Finished with high-end outdoor epoxy power, resistant corrosion |
|
Color |
Grey/Black/White |
|
Tightness Level |
IP66 |
|
Impact Resistance |
IK08 |
|
Standards & Certifications |
CE/ENEC/CB/GS/IEC/ROHS/LM80/TM21 |
